If clicked Yes, Orion discovery will run. Once completed, Network Atlas will pop up with a notification message informing you of how many objects are new to the Orion database (if any) and if you want to discover them. An automatic map import window opens, choose the desired map file(s) from the list to be imported.
#Starwind network topology mapper update
Hit on the discover or update button to complete the wizard. Enter your Orion Server log-in details (where your active Network Atlas resides), make sure to test the credentials and hit the Set button. Next, make sure Keep Network Atlas updated with these discovery results is ticked ON.
Save results as a new map – There will always be a new map created and saved with time-stamps. Manually select results to merge with a map - Users will need to choose the required map(s) to be displayed into Network Atlas from the available completed scans. Automatically merge results with a map – This option will always merge the new discovered data with the old. In order to enable the scheduling function, setup the scheduling frequency in the Network Discovery Scan Wizard.Ĭhoose on how you want to save the discovered results to bring up the map in Network Atlas. Schedule Export: Users can also schedule the export of NTM Maps into Network Atlas, there by staying ahead of network changes in your environment. Note: For both these choices there is a need to save the map first and an option to secure your map by a password. Export as a Map – Choose this option if you want to save the map and bring it up into Network Atlas at a later stage. Open directly in Network Atlas – This function will trigger the launch of Network Atlas in the background. One-Time Export: You can easily export your discovered map to Network Atlas using the following flow File – Export – Network Atlas. The application, provides two ways to export your maps/diagrams into Network Atlas Once imported, the user has the choice to add the nodes identified in NTM into the Orion database or simply display the identified nodes. Network Topology Mapper has the capability of exporting the network diagram it has discovered and rendered to Network Atlas and Vice Versa. With the combination of SolarWinds Network Topology Mapper (NTM) and Orion Network Performance Monitor (NPM), now you can have your cake and eat it too! But, maybe you want a complete topology map of your network environment (example: Workstations, Printers, Hubs etc) for documentation purposes or to know what’s on your network and represent those devices on you Orion Web console, without actively monitoring them. and not every single object in your environment. With Network Performance Monitor (NPM) one monitors key devices, interfaces, etc. Network Topology Mapper is a replacement to its earlier network mapping application called LANSurveyor It can automatically discover, map, provide inventory and document your specific network environment. #Starwind network topology mapper software
The software is built to create dynamic topology diagrams/maps by using its powerful auto-discovery engine. Is an automated Network Mapping software.
Using the Connect Now button the application automatically draw connections between the nodes. It is a semi-manual network diagramming software which allows users to design and draw physical & logical topology diagrams by manually placing discovered nodes on to the map canvas. Is a powerful tool built for creating custom network maps and diagram. To answer this question, we got to understand what use-cases these two applications solves. I have had number of customer interviews lately and the most common question which arises quite often is, I have Orion Network Atlas why do I need another network mapping software? NETWORK TOPOLOGY MAPPER INTEGRATION WITH NETWORK ATLAS
